Explosion-proof portable spotlight Cast Aluminium
EVJD
This light and portable spotlight is perfect for all maintenance operations in zones 1 or 2, where portable lighting is required.
Aluminium cast
Very easy maintenance (just one screw to change the lamp)
Exe connection chamber
Outstanding photometric efficiency
Voir Plus
-
Zones
-
Ingress Protection
-
Material
Lead time :
Log in to access tariffs
LOG IN - NOT ONLINE - CONTACT US
| Selection criteria |
|
|
EVJD
Explosion-proof portable spotlight Cast Aluminium
Authorisation(s) and certification(s)
Unfold CloseAvec ampoule SHP 70W
II 2G Ex d e IIC Gb (-20°C à +40°C)
II 2D Ex tb IIIC T120°C Db IP66/67 (-20°C à +40°C)
Technical characteristics
Unfold Close| Product description : | Explosion-proof portable spotlight Cast Aluminium |
| Lighting source | Halogen |
| Sleeve | R7s |
| Ingress Protection | IP66 / IP67 |
| Min Operating Temperature | -20 Degree Celsius |
| Max Operating Temperature | 50 Degree Celsius |
| Zones | Zones 1, 2, 21, 22 |
| Power supply frequency | 50 Hz |
| Cable entries | 2 x M20 |
| Max. Cable size | 6.000 Square Millimeter |
| Width | 331.000 Millimeter |
| Height | 285.000 Millimeter |
| Depth / Thickness | 215.000 Millimeter |
| Weight | 10 Kg |
| Material | Aluminium |
| Material of the diffuser | Glass |
| Fixing mounting | Stainless steel mounting bracket (supplied) |
| Puissance Lumineuse en Watts | 300, 70 |
| Tolerance | 220-254 VAC |
| Voltage - Current Type | VAC |
| Voltage | 230 |
