PL511-STD
Pre-fitted junction boxes GRP ATEX 114x114mm IP66 housing
Log in to access tariffs
This strobe’s visual power makes it suitable for outdoor use, and in the harshest conditions thanks to its LM7 aluminium design.
Plus pointsAluminium housing LM6
Very easy wiring
Two cable entries on the same side
Internal and external earth terminal
Protective grid included
Selection criteria |
|
BEXBG21D1156
Compact 21J 485cd ATEX strobe light 115Vac 550mA Green IP66/IP67
II 2G Ex d IIC T4 Ta. -50°C à +55°C
II 2G Ex d IIC T3 Ta. -50°C à +70°C
II 2D Ex tD A21 IP67 T200
Product description : | Compact 21J 485cd ATEX strobe light 115Vac 550mA Green IP66/IP67 |
Functions | Flash |
Lighting source | Xenon |
Effective Range in Joules | 21 Joule |
Effective Range in Candelas | 485 Candela |
Flash Rate | 1 Hz (60 Flashs/mn) - 2 Hz (120 Flashs/mn) |
Average life time of the flash | 70% efficiency after 8 million Flashes |
Synchronisation | Yes (in parallel mounting) |
Ingress Protection | IP66 / IP67 |
Min Operating Temperature | -50 Degree Celsius |
Max Operating Temperature | 70 Degree Celsius |
Protection Grid | Incluse |
Zones | Zones 1, 2, 21, 22 |
Relative Humidity | 90% at 20°C |
Cable entries | 2 x M20 (Plugs and cable glands supplied) |
Min.Cable size | 0.500 Square Millimeter |
Max. Cable size | 4.000 Square Millimeter |
Power Factor | 100 % |
Width | 165.000 Millimeter |
Height | 246.000 Millimeter |
Housing Material | Aluminium LM6 |
Optical Materials | Glass |
Fixing mounting | Fixing on adjustable bracket |
Mounting | Surface mounting |
Wall mounted | Yes |
Ceiling mounted | Yes |
Colour (material) | Red |
Available Lens Colours | Green |
Voltage - Current Type | VAC |
Voltage | 115 |
Tolerance | +/- 10% VAC |
Nominal consumption | 560 mA |
Weight | 2,95 Kg |
